- Open Access
Effects of glycemic control on glucose utilization and mitochondrial respiration during resuscitated murine septic shock
Intensive Care Medicine Experimental volume 2, Article number: 19 (2014)
This study aims to test the hypothesis whether lowering glycemia improves mitochondrial function and thereby attenuates apoptotic cell death during resuscitated murine septic shock.
Immediately and 6 h after cecal ligation and puncture (CLP), mice randomly received either vehicle or the anti-diabetic drug EMD008 (100 μg · g-1). At 15 h post CLP, mice were anesthetized, mechanically ventilated, instrumented and rendered normo- or hyperglycemic (target glycemia 100 ± 20 and 180 ± 50 mg · dL-1, respectively) by infusing stable, non-radioactive isotope-labeled 13C6-glucose. Target hemodynamics was achieved by colloid fluid resuscitation and continuous i.v. noradrenaline, and mechanical ventilation was titrated according to blood gases and pulmonary compliance measurements. Gluconeogenesis and glucose oxidation were derived from blood and expiratory glucose and 13CO2 isotope enrichments, respectively; mathematical modeling allowed analyzing isotope data for glucose uptake as a function of glycemia. Postmortem liver tissue was analyzed for HO-1, AMPK, caspase-3, and Bax (western blotting) expression as well as for mitochondrial respiratory activity (high-resolution respirometry).
Hyperglycemia lowered mitochondrial respiratory capacity; EMD008 treatment was associated with increased mitochondrial respiration. Hyperglycemia decreased AMPK phosphorylation, and EMD008 attenuated both this effect as well as the expression of activated caspase-3 and Bax. During hyperglycemia EMD008 increased HO-1 expression. During hyperglycemia, maximal mitochondrial oxidative phosphorylation rate was directly related to HO-1 expression, while it was unrelated to AMPK activation. According to the mathematical modeling, EMD008 increased the slope of glucose uptake plotted as a function of glycemia.
During resuscitated, polymicrobial, murine septic shock, glycemic control either by reducing glucose infusion rates or EMD008 improved glucose uptake and thereby liver tissue mitochondrial respiratory activity. EMD008 effects were more pronounced during hyperglycemia and coincided with attenuated markers of apoptosis. The effects of glucose control were at least in part due to the up-regulation of HO-1 and activation of AMPK.
Hyperglycemia is the hallmark of sepsis-induced metabolic stress [1, 2] and is caused by both inhibition of insulin-mediated glucose uptake , i.e., insulin resistance [1–3], insufficient insulin secretion , as well as increased hepatic glucose production from glycogenolysis and gluconeogenesis . It is well-established that sepsis-induced hyperglycemia is associated with oxidative stress [5, 6], which causes mitochondrial dysfunction and organ damage in the kidney [7, 8], the heart , and the liver  when present over prolonged time. Maintaining normoglycemia by insulin control at different nutritional intake levels protected against such mitochondrial and organ damage [7, 8]. These studies indicated that glycemia-independent effects of insulin appeared to be marginal in this context: blood glucose control with insulin did not enhance the protective effect of normoglycemia per se, and combining hyperglycemia and hyperinsulinemia was associated with the most pronounced mitochondrial damage and organ injury . Moreover, insulin has marked immunologic effects , e.g., by inhibition of glycogen synthase kinase-3β [9, 10]. Finally, tight blood glucose control with insulin may lead to episodes of deleterious hypoglycemia [11, 12]. Metformin, a first line-defense drug for the treatment of type 2 diabetes may theoretically circumvent the undesired side effects of insulin . Metformin attenuated both the LPS-induced hyper-inflammatory response after partial hepatectomy  and oxidative stress due to mild inhibition of the mitochondrial complex I , decreases hepatic gluconeogenesis , and improves whole-body glucose oxidation during hyperglycemia . Metformin also stabilizes mitochondrial functioning by reducing the transition pore opening, which protects against ischemia- , oxidant- [19, 20], or hyperglycemia-induced  cell death. Finally, it stimulates mitochondrial biogenesis via PG1α signaling , which in turn coincided with survival in patients with sepsis . However, metformin use is limited by its rare but serious side effect, lactic acidosis, which could develop in this context due to the frequent renal impairment associated with septic shock [24–26]. Since we recently demonstrated acute kidney injury during murine septic shock , we therefore tested the hypothesis whether lowering glycemia using EMD008 would allow improving mitochondrial function and thereby attenuate apoptotic cell death. EMD008 was chosen because it lowers ATP/ADP ratios similar to metformin, which should activate AMPK and thereby improve hepatic and skeletal muscle glucose utilization  and uptake. EMD008 alleviates glucotoxic stimulation of apoptosis without or induction of hypoglycemia. In contrast to metformin, these effects are not based on an inhibition of mitochondrial complex I and the reduction of mitochondrial respiration and cytosolic NADH/NAD+ ratio is less pronounced, reducing the risk of lactic acidosis (all findings pertaining to EMD008 are personal communications of XL). Septic shock with normotensive, hyperdynamic hemodynamics resulting from fluid resuscitation and continuous i.v. noradrenaline was investigated in order to exclude any systemic hemodynamic effect on metabolism: in fact, the above-mentioned data originate from long-term experiments in awake, spontaneous breathing animals presenting with lower-organ O2 supply than in healthy control animals [7, 8].
Anesthesia, surgical instrumentation, and experimental protocol
The study protocol was approved by the University Animal Care Committee and the federal authorities for animal research of the Regierungspräsidium Tübingen, Baden-Württemberg. Male C57BL/6 J mice (body weight 23 to 29 g, age 10 to 16 weeks) were used for the experiments, which were performed in adherence to the National Institutes of Health Guidelines on the Use of Laboratory Animals. The animals, which did not undergo mechanical ventilation and surgical instrumentation, served as controls for tissue immunoblotting and electrophoretic mobility shift assay (EMSA). The anesthesia, cecal ligation and puncture (CLP) procedure and the surgical instrumentation have been described in detail previously [27, 29]. Mice were anesthetized with sevoflurane and received s.c. buprenorphine together with acetated Ringer's solution containing glucose (4 or 12 mg · g-1 for normoglycemic and hyperglycemic animals). A midline laparotomy was performed to identify and ligate the cecum followed by a single puncture (18-gauge needle). After squeezing to expel stool, the cecum was returned into the abdominal cavity. Postoperatively, water and food were provided ad libitum. After 6 h, mice received a second s.c. injection including buprenorphine, acetated Ringer's solution containing glucose as described above together with ceftriaxone and clindamycin (each with 30 μg · g-1). Fifteen hours post CLP, mice were anesthetized with sevoflurane followed by i.p. ketamine (120 μg · g-1), midazolam (125 μg · g-1), and fentanyl (0.25 μg · g-1). After placement of the animal on the procedure bench equipped with a heating pad and a lamp, a rectal temperature probe was inserted. The anterior neck was incised to expose the trachea, the right internal jugular vein, and the right carotid artery. The trachea was intubated, and the lungs were mechanically ventilated with a pressure-controlled, lung-protective ventilation strategy using a small animal ventilator (FlexiVentTM, Scireq®, Montreal, Canada) [27, 29, 30]. After a lung recruitment maneuver, respirator settings were FiO2 0.5, tidal volume 6 to 8 μL · g-1 (titrated to maintain arterial PCO2 at 30 to 40 mmHg), respiratory rate 160 breaths · min-1, inspiratory/expiratory time ratio 1:2, and PEEP 5 cm H2O. Catheters were inserted into the jugular vein, the carotid artery, and the bladder. Anesthesia was maintained with continuous i.v. ketamine, fentanyl and midazolam, titrated to reach deep sedation and analgesia as documented by complete tolerance against noxious stimuli. Normotensive hemodynamics (i.e., mean arterial pressure > 55 mmHg) were achieved by i.v. hydroxyethyl starch (maximum infusion rate 20 μL · g-1 · h-1) in a balanced electrolyte solution (Tetraspan 6%, Braun, Melsungen, Germany), and, if needed, together with continuous i.v. norepinephrine. Animals were randomly assigned to injection of vehicle (0.9% saline) or EMD008 (100 μg · g-1) twice s.c., immediately and 6 h after the CLP procedure and i.v. after insertion of the jugular vein catheter. In addition, animals received either 1 or 2 mg · g-1 · h-1 continuous i.v. glucose to achieve a normo- (target glycemia 100 ± 20 mg · dL-1; vehicle n = 8, EMD008 n = 7) or hyperglycemic (target glycemia 180 ± 50 mg · dL-1; vehicle n = 10, EMD008 n = 11) conditions, respectively. Infused glucose 50% was given as stable, non-radioactive-labeled 1,2,3,4,5,6-13C6-glucose. After 5 h, the animals were killed through blood withdrawal via the vena cava inferior.
Cell extracts, immunoblots, and comet assay
Immediately postmortem, the liver was removed, snap-frozen, and stored at -80°C. Frozen tissue was homogenized and lysed in lysing buffer 100 mM Tris pH 7.5; 500 mM NaCl; 6 mM EDTA; 6 mM EGTA; 2% Triton-X-100; 1% NP 40; 20% glycerol; protease inhibitors (β-glycerolphosphat 2 mM; DTT 4 mM; leupeptin 20 μM; pNPP (p-nitrophenylphosphate) 4 mM; natriumorthovanadate 0.2 mM). To assess the expression of AMPK-α, p(Thr172)-AMPK-α, activated caspase-3, and heme oxygenase-1 (HO-1) equal total protein aliquots (20 μg) were separated by SDS-PAGE and transferred by western blotting. After blocking, the gel membranes were incubated with primary antibodies (anti-AMPK-α; anti-p(Thr172)-AMPK- α; anti-Bax; anti-cleaved caspase-3 (Cell Signaling, Danvers, MA, USA); anti-HO-1 (Abcam, Cambridge, NY, USA)). Actin, with a primary antibody from Santa Cruz, Dallas, TX, USA, was used as loading control. The primary antibodies were detected using horseradish peroxidase-conjugated secondary antibodies (Cell Signaling, Danvers, MA, USA or Santa Cruz, Dallas, TX, USA). The membranes were subjected to chemiluminescence using SuperSignal West Femto Maximum Sensitivity Substrate (Thermo Fisher Scientific, Waltham, MA, USA). Exposed films were scanned, and intensity of immunoreactivity was measured using NIH ImageJ software (http://rsb.info.nih.gov/nih-image). Protein expressions are presented as x-fold increase over control values. These control values were taken from samples of two healthy, native animals, which were co-separated on each gel. AMPK stimulation is expressed as the ratio of p(Thr172)-AMPK-α/AMPK-α.
Single-cell gel electrophoresis allowed assessing the oxidative deoxyribonucleic acid (DNA) damage (‘tail moment’ in the alkaline version of the comet assay) [27, 31]. Immediate postmortem biopsies were placed in buffer containing Na-ethylenediaminetetraacetic acid and minced to obtain a cell suspension. Two agarose gel slides were prepared from each biopsy. The mean tail moment of 100 nuclei analyzed per slide was used for each animal.
For the measurement of blood glucose concentrations and 13C6-glucose tracer enrichment, plasma samples were spiked with 6,6-2H2-glucose for concentration determination, with an amount targeted to achieve a 2H2-tracer mole fraction of 50%. The spiked samples were derivatized with N-methyl-bis(trifluoroacetamide) (MBTFA, abcr, Karlsruhe, Germany) to obtain the trifluoroacetyl-glucose derivative . The latter was analyzed by GC/MS under electron impact determination, and the signals at (m/z) 319, 321, and 325 were recorded for the 2H2- and 13C6-tracer mole fraction determination. Expiratory gas, 1 ml, was continuously collected as an aliquot of 60 to 80 respiratory cycles from the expiratory branch to determine both expiratory CO2 concentration and 13CO2 tracer enrichment using GC/MS and measuring the masses m/z 44 and m/z 45. CO2 production rates were calculated as the product of tidal volume, respiratory rate, and CO2 concentration. During steady-state conditions, the glucose rate of appearance (Ra) is derived from the arterial plasma isotope enrichment (atom percentage excess or APE) according to Equation 1:
where APEpl is the isotope enrichment in the plasma, and F is the infusion rate of the labeled glucose . Endogenous glucose production is the difference between Ra and the total exogenous glucose infusion, 2 · F. Since glycogenolysis most likely was hardly present any longer , endogenous glucose production is assumed to equal gluconeogenesis (GNG).
The activity of the mitochondrial respiratory chain was measured in immediate postmortem homogenized liver samples with disrupted cell membranes and intact mitochondria using ‘high-resolution respirometry’ (Oxygraph-2 k respirometer; OROBOROS Instruments Corp, Innsbruck, Austria) [31, 34]. Data reported are maximal oxidative phosphorylation, i.e., O2 consumption after addition of substrates of complexes I and II (pyruvate 10 mM, malate 5 mM + glutamate 10 mM, and succinate 10 mM) and ADP (5 mM) and maximal O2 consumption in the uncoupled state, i.e., after 4-(trifluoromethoxy) phenylhydrazone (FCCP), respectively.
Tracer data evaluation
The 1,2,3,4,5,6-13C6-glucose plasma and mixed expiratory 13CO2 tracer isotope enrichment data allowed for calculating the flow rates of gluconeogenesis and glucose oxidation. During steady state conditions, whole-body glucose uptake (uptake) equals the sum of gluconeogenesis (GNG) and exogenous glucose infusion. In order to determine the relation between glucose uptake and glycemia as well as a possible effect of EMD008, the measured flux data were analyzed using a mathematical model based on the assumption that these flow rates are directly closely linked to the plasma glucose availability (conc) and the AMPK activation (ampk). The latter was integrated into that model because AMPK is a crucial regulator of cellular glucose disposal  that also contributes to the glycemic effect of metformin . A potential link between flow rates and the two controlling factors, glycemia and AMPK activation, was explored by regression analysis. Since all the variables involved in the regression are determined with a certain measurement error, an error in all variables approach was used adjusting all measured flow rates and controlling factors as close as possible to their corresponding measurement values, satisfying the following Equation 2:
where the coefficients k1 and k2 quantify the impact of the glucose concentration and AMPK activation, respectively. In analogy, an equation was defined to express gluconeogenesis as a function of the controlling factors. An impact is established if the regression estimate for the corresponding coefficient is significantly different from 0. Hyperglycemic and normoglycemic animals were analyzed with the same set of coefficients, assuming that the sensitivity of flow rates to changes in the control processes remains the same for all conditions. Vehicle and EMD008-treated animals were analyzed with both distinct and the same sets of coefficients to explore whether AMPK activity alone is sufficient to explain the EMD008 effect. Details of the regression approach are given in the Additional file 1.
Differences between groups were analyzed with a one-way Kruskal-Wallis analysis of variance on ranks followed by a post hoc Dunn's test. Differences between EMD008 and vehicle were tested with a student's t test or a Mann-Whitney rank sum as appropriate according to data distribution. The regression was performed using the STAN software package , which expands on the Bayesian statistical package WinBUGS  (BUGS = Bayesian statistics using Gibbs sampling). It allows a flexible definition of the statistical model and makes no assumption about the distribution of a test statistics but estimates it using MCMC sampling given the data and eventually prior information. It thereby provides reliable estimates of the 95% confidence range for parameters of interest, which are used here as indicator for significance.
Despite the maximum colloid infusion rate allowed by the protocol, all mice needed continuous i.v. norepinephrine to maintain target hemodynamics, which were lower in the normoglycemic EMD008-treated animals (0.009 (0.08 to 0.012) μg · g-1 · h-1) vs. all other groups (p < 0.05, hyperglycemia, vehicle 0.025 (0.011 to 0.062), hyperglycemia EMD008 0.030 (0.022 to 0.183), normoglycemia vehicle 0.031 (0.027 to 0.205)). Table 1 summarizes the parameters of systemic and regional macro- and microcirculatory perfusion, gas exchange, and acid-base status, without inter-group difference. However, in the normoglycemia group, EMD008 treatment prevented the progressive fall of arterial pH present in the other experimental groups. Table 2 summarizes the results of the metabolic measurements. According to the protocol, blood glucose levels were higher in the hyperglycemia groups, which coincided with more pronounced hyperlactatemia. EMD008 lowered blood glucose concentrations in these animals, whereas it had no effect in the normoglycemic mice. While whole-body CO2 production and direct aerobic glucose oxidation were comparable between groups, hepatic gluconeogenesis was significantly lower in the hyperglycemic animals. In the latter, EMD008 further increased gluconeogenesis. Table 2 also demonstrates that hyperglycemia lowered both maximal oxidative phosphorylation and maximal electron transfer capacity in the uncoupled state in liver mitochondria and that EMD008 treatment was associated with increased mitochondrial respiration, no matter what the glycemia level is. Table 3 summarizes the immune biology results. Hyperglycemia was associated with decreased phosphorylation of AMPK, and EMD008 attenuated this effect. EMD008 significantly attenuated the expression of Bax during hyperglycemia and that of activated caspase-3 under normoglycemia. While EMD008 increased HO-1 expression during hyperglycemia, it had no effect in the normoglycemic animals. Liver tissue tail moment obtained from the comet assay was comparable in all groups.
Figure 1 shows the relation between mitochondrial respiration and HO-1 expression or AMPK activation. During hyperglycemia, the maximal mitochondrial oxidative phosphorylation rate was directly related to HO-1 expression (p < 0.05) (Figure 1A, left panel), while there was no relationship during normoglycemia (Figure 1A, right panel). In contrast, mitochondrial oxidative phosphorylation was unrelated to AMPK activation, no matter what the glycemia level is (Figure 1B). During hyperglycemia, HO-1 expression was directly related to AMPK activation (p < 0.05) (Figure 1C, left panel), while no significant relation was present during normoglycemia (Figure 1C, right panel). Figure 2 summarizes the results of the mathematical modeling of the isotope enrichment data. Assuming in Equation 1 that AMPK activation was not affected by the level of glycemia, the mathematical modeling demonstrated that EMD008 caused an upward shift of the linear relationship between glucose disposal and blood glucose concentration without affecting its slope, i.e., EMD008 treatment increased cellular glucose uptake, no matter what the actual level of glycemia is (Figure 2A). In turn, when the effect of glycemia on AMPK activation was taken into account in Equation 1, EMD008 increased the slope of the relation between glucose disposal and glycemia (Figure 2B), i.e., increased glucose disposal at a given level of glycemia.
This study was to test the hypothesis whether glycemic control using the newly developed anti-diabetic drug EMD008 would improve glucose uptake and thereby increase the mitochondrial respiratory activity of murine resuscitated, polymicrobial septic shock. EMD008 was chosen to reduce blood sugar levels rather than insulin or metformin to avoid any insulin-induced hypoglycemia and lactic acidosis, respectively. The major findings were as follows: (i) EMD008 increased both liver tissue oxidative phosphorylation and maximal O2 uptake, (ii) this effect was even more pronounced during normoglycemia, (iii) associated with attenuated markers of tissue apoptosis, and (iv) associated with an up-regulation of HO-1 and activation of AMPK.
Hyperglycemia was associated with significantly lower mitochondrial oxidative phosphorylation and maximal O2 consumption in the uncoupled state. Controlling glycemia restored mitochondrial capacity, and EMD008 further enhanced this effect. Our findings of a hyperglycemia-induced depression of mitochondrial capacity extends previous reports on tissue respiration by Vanhorebeek in a long-term, un-resuscitated rabbit model of burn injury-induced critical illness [7, 8], inasmuch as hyperglycemia has similar effects during the acute phase of noradrenaline-resuscitated murine septic shock. At a first glance, increased tissue respiration could be induced by the noradrenaline intervention alone as reported by other authors for liver mitochondrial respiration during long-term porcine endotoxemia . These authors, however, compared noradrenaline treatment to fluid resuscitation alone, whereas in our experiment, all mice received continuous i.v. noradrenaline to achieve target hemodynamics. Furthermore, we explicitly studied the effect of hyperglycemia in comparison to normoglycemia, while glycemia was maintained between 63 and 108 mgmol · dL-1 in that study.
Hyperglycemia per se was associated with significantly higher Bax expression, while EMD008 attenuated caspase-3 activation during normoglycemia. As a whole, these findings agree with various previous reports that hyperglycemia causes liver tissue apoptosis [39–42], which can be prevented by anti-diabetic drugs such as metformin [20, 21, 43], even during acute stress states . Attenuation of apoptosis resulting from glucose control per se[39–42] and/or metformin treatment [20, 21, 43, 44] is mainly referred to decreased oxidative stress associated with restoration of normoglycemia [7, 8]. Metformin reduces oxidative stress due to inhibition of complex I and a consecutive decrease of mitochondrial O2 uptake [15, 19, 21, 45]. EMD008 treatment coincided with increased mitochondrial respiration, no matter what the level of glycemia is. Hence, it exhibited protective effects on mitochondrial function without reducing mitochondrial O2 consumption. Moreover, the tail moment in the comet assay, which previously proved to be a sensitive marker of tissue oxidative stress both in our murine model of resuscitated septic shock [31, 46] as well as in hyperglycemic rats [40, 42], did not show any inter-group difference. Consequently, a postulated key mechanism of metformin action, namely, complex I inhibition that reduces both ROS production and mitochondrial O2 consumption, may not contribute to EMD008 effects and other mechanisms are likely to be involved. Figure 1 demonstrates that at each level of glycemia, EMD008 treatment coincided with the highest individual values of HO-1 expression. During hyperglycemia, EMD008 not only significantly increased HO-1 expression when compared to the vehicle-treated animals, but there also was a significant direct relation between mitochondrial respiratory capacity and HO-1 expression. Up-regulation of HO-1 is an adaptive response against oxidative stress-induced mitochondrial dysfunction during streptozotocin-induced diabetes . During the transition from acute to chronic 3,5-diethoxycarbonyl-1,4-dihydrocollidine hepatotoxicity , it counteracts mitochondrial dysfunction and energetic failure. Induction of HO-1 induction was associated with increased release of anti-inflammatory cytokines and hepatic mitochondrial biogenesis in endotoxic shock , which ultimately protected against otherwise lethal Staphylococcus aureus sepsis . Finally, activation of HO-1 with hemin improved glucose metabolism in diabetic rats  as a result of synergistic interaction between HO-1 and AMPK . In our experiments, during hyperglycemia, HO-1 expression was directly related to AMPK activation, and the mathematical modeling of the glucose enrichment data depicted in Figure 2 suggests that the EMD008-associated increase in cellular glucose utilization was due to the higher AMPK activation as well. Hence, it is tempting to speculate that during hyperglycemia, the EMD008 effects were at least in part due to AMPK activation. This reasoning agrees with previous work: In vitro, AMPK activation by HO-1  or metformin  attenuated complement-induced cytotoxicity and TNF-α-induced inflammation, respectively. In turn, activation of AMPK can stimulate HO-1 expression and thereby attenuate cytokine-mediated cell death . In vivo, in endotoxic mice, the metformin-induced attenuation of the hyper-inflammatory response ultimately resulting in increased survival was at least in part due to AMPK activation .
The present data link AMPK-activation with HO-1 induction and improved mitochondrial respiration under hyperglycemia. The latter implies improved oxidative glucose utilization, and as a consequence, an improved flow and removal of glycolytic metabolites. Increased levels of glycolytic metabolites are the primary cause for glucotoxicity , and their increased oxidative disposal should lead to lower metabolite levels and explain the observed tendency of a reduced glucotoxity. More importantly, if one considers that net glucose uptake is by part driven by an intracellular/extracellular concentration gradient, then lower intracellular metabolite levels should lead to a higher glucose uptake. To a certain extent, improved mitochondrial activity pulls extracellular glucose down the glycolytic pathway. Such a mechanism can explain the link between glucose uptake and AMPK stimulation and allows an increased glucose uptake without increasing intracellular metabolite levels and glucotoxicity. Improved hepatic mitochondrial respiration should improve the energy state. Various steps of gluconeogenesis require ATP, and it may well be that under septic conditions the gluconeogenic rate, albeit high, is limited by energy supply and the improved energy supply supersedes other effects of AMPK or EMD008 that downregulate gluconeogenesis under energy-sufficient conditions.
Limitations of the study
All animals received continuous i.v. noradrenaline to achieve hemodynamic targets, but the noradrenaline infusion rate was significantly reduced by EMD008 during normoglycemia. It is unlikely, however, that the improved mitochondrial respiration under these conditions was only due to the reduced catecholamine administration: under hyperglycemic conditions, EMD008 also improved mitochondrial respiratory capacity despite virtually identical noradrenaline requirements. It could be argued that the higher rate of gluconeogenesis associated with the EMD008 treatment is in contrast to the reduced glucose formation expected from the actions of metformin. However, our finding is in line with previous observations in this model demonstrating that higher rates of hepatic gluconeogenesis coinciding with unchanged or even lower catecholamine infusion rates indicate improved hepatic metabolic performance [27, 58].
During resuscitated, polymicrobial, murine septic shock, glycemic control either by reducing glucose infusion rates or by using the newly developed anti-diabetic drug EMD008 improved glucose uptake and thereby both liver tissue oxidative phosphorylation and maximal O2 uptake. The EMD008 effects were more pronounced during hyperglycemia and coincided with attenuated markers of tissue apoptosis. These beneficial effects of glucose control were at least in part due to up-regulation of HO-1 and activation of AMPK.
Mizock BA: Alterations in carbohydrate metabolism during stress: a review of the literature. Am J Med 1995, 98: 75–84. 10.1016/S0002-9343(99)80083-7
Losser MR, Damoisel C, Payen D: Bench-to-bedside review: glucose and stress conditions in the intensive care unit. Crit Care 2010, 14: 231. 10.1186/cc9100
Marik PE, Raghavan M: Stress-hyperglycemia, insulin and immunomodulation in sepsis. Intensive Care Med 2004, 30: 748–756. 10.1007/s00134-004-2167-y
Watanabe Y, Singamsetty S, Zou B, Guo L, Stefanovski D, Alonso LC, Garcia-Ocana A, O'Donnell CP, McVerry BJ: Exogenous glucose administration impairs glucose tolerance and pancreatic insulin secretion during acute sepsis in non-diabetic mice. PLoS One 2013, 8: e67716. 10.1371/journal.pone.0067716
Esposito K, Nappo F, Marfella R, Giugliano G, Giugliano F, Ciotola M, Quagliaro L, Ceriello A, Giugliano D: Inflammatory cytokine concentrations are acutely increased by hyperglycemia in humans - role of oxidative stress. Circulation 2002, 106: 2067–2072. 10.1161/01.CIR.0000034509.14906.AE
Leverve X: Hyperglycemia and oxidative stress: complex relationships with attractive prospects. Intensive Care Med 2003, 29: 511–514.
Vanhorebeek I, Gunst J, Ellger B, Boussemaere M, Lerut E, Debaveye Y, Rabbani N, Thornalley PJ, Schetz M, Van den Berghe G: Hyperglycemic kidney damage in an animal model of prolonged critical illness. Kidney Int 2009, 76: 512–520. 10.1038/ki.2009.217
Vanhorebeek I, Ellger B, De Vos R, Boussemaere M, Debaveye Y, Perre SV, Rabbani N, Thornalley PJ, Van den Berghe G: Tissue-specific glucose toxicity induces mitochondrial damage in a burn injury model of critical illness. Crit Care Med 2009, 37: 1355–1364. 10.1097/CCM.0b013e31819cec17
Dugo L, Collin M, Allen DA, Murch O, Foster SJ, Yaqoob MM, Thiemermann C: Insulin reduces the multiple organ injury and dysfunction caused by coadministration of lipopolysaccharide and peptidoglycan independently of blood glucose: role of glycogen synthase kinase-3β inhibition. Crit Care Med 2006, 34: 1489–1496. 10.1097/01.CCM.0000215457.83953.E3
Dugo L, Collin M, Thiemermann C: Glycogen synthase kinase 3β as a target for the therapy of shock and inflammation. Shock 2007, 27: 113–123. 10.1097/01.shk.0000238059.23837.68
Brunkhorst FM, Engel C, Bloos F, Meier-Hellmann A, Ragaller M, Weiler N, Moerer O, Gruendling M, Oppert M, Grond S, Olthoff D, Jaschinski U, John S, Rossaint R, Welte T, Schaefer M, Kern P, Kuhnt E, Kiehntopf M, Hartog C, Natanson C, Loeffler M, Reinhart K, German Competence Network Sepsis (SepNet): Intensive insulin therapy and pentastarch resuscitation in severe sepsis. N Engl J Med 2008, 358: 125–139. 10.1056/NEJMoa070716
Preiser JC, Devos P, Ruiz-Santana S, Mélot C, Annane D, Groeneveld J, Iapichino G, Leverve X, Nitenberg G, Singer P, Wernerman J, Joannidis M, Stecher A, Chioléro R: A prospective randomised multi-centre controlled trial on tight glucose control by intensive insulin therapy in adult intensive care units: the Glucontrol study. Intensive Care Med 2009, 35: 1738–48. 10.1007/s00134-009-1585-2
Christiansen CF, Johansen MB, Christensen S, Brien JMO, Tønnesen E, Sørensen HT: Preadmission metformin use and mortality among intensive care patients with diabetes: a cohort study. Crit Care 2013, 17: R192. 10.1186/cc12886
Bergheim I, Luyendyk JP, Steele C, Russell GK, Guo LP, Roth RA, Arteel GE: Metformin prevents endotoxin-induced liver injury after partial hepatectomy. J Pharmacol Exp Ther 2006, 316: 1053–1061.
Batandier C, Guigas B, Detaille D, El-Mir M, Fontaine E, Rigoulet M, Leverve XM: The ROS production induced by a reverse-electron flux at respiratory-chain complex 1 is hampered by metformin. J Bioenerg Biomembr 2006, 38: 33–42. 10.1007/s10863-006-9003-8
Argaud D, Roth H, Wiernsperger N, Leverve XM: Metformin decreases gluconeogenesis by enhancing the pyruvate-kinase flux in isolated rat hepatocytes. Eur J Biochem 1993, 213: 1341–1348. 10.1111/j.1432-1033.1993.tb17886.x
Gore DC, Wolf SE, Herndon DN, Wolfe RR: Metformin blunts stress-induced hyperglycemia after thermal injury. J Trauma 2003, 54: 555–561. 10.1097/01.TA.0000026990.32856.58
Bhamra GS, Hausenloy DJ, Davidson SM, Carr RD, Paiva M, Wynne AM, Mocanu MM, Yellon DM: Metformin protects the ischemic heart by the Akt-mediated inhibition of mitochondrial permeability transition pore opening. Basic Res Cardiol 2008, 103: 274–284. 10.1007/s00395-007-0691-y
Guigas B, Detaille D, Chauvin C, Batandier C, De Oliveira F, Fontaine E, Leverve X: Metformin inhibits mitochondrial permeability transition and cell death: a pharmacological in vitro study. Biochem J 2004, 382: 877–884. 10.1042/BJ20040885
El-Mir MY, Detaille D, R-Villanueva G, Delgado-Esteban M, Guigas B, Attia S, Fontaine E, Almeida A, Leverve X: Neuroprotective role of antidiabetic drug metformin against apoptotic cell death in primary cortical neurons. J Mol Neurosci 2008, 34: 77–87. 10.1007/s12031-007-9002-1
Detaille D, Guigas B, Chauvin C, Batandier C, Fontaine E, Wiernsperger N, Leverve X: Metformin prevents high-glucose-induced endothelial cell death through a mitochondrial permeability transition-dependent process. Diabetes 2005, 54: 2179–2187. 10.2337/diabetes.54.7.2179
Kukidome D, Nishikawa T, Sonoda K, Imoto K, Fujisawa K, Yano M, Motoshima H, Taguchi T, Matsumura T, Araki E: Activation of AMP-activated protein kinase reduces hyperglycemia-induced mitochondrial reactive oxygen species production and promotes mitochondrial biogenesis in human umbilical vein endothelial cells. Diabetes 2006, 55: 120–127. 10.2337/diabetes.55.01.06.db05-0943
Carré JE, Orban JC, Re L, Felsmann K, Iffert W, Bauer M, Suliman HB, Piantadosi CA, Mayhew TM, Breen P, Stotz M, Singer M: Survival in critical illness is associated with early activation of mitochondrial biogenesis. Am J Respir Crit Care Med 2010, 182: 745–751. 10.1164/rccm.201003-0326OC
Vecchio S, Protti A: Metformin-induced lactic acidosis: no one left behind. Crit Care 2011, 15: 107. 10.1186/cc9404
Protti A, Fortunato F, Monti M, Vecchio S, Gatti S, Comi GP, De Giuseppe R, Gattinoni L: Metformin overdose, but not lactic acidosis per se, inhibits oxygen consumption in pigs. Crit Care 2012, 16: R75. 10.1186/cc11332
Protti A, Lecchi A, Fortunato F, Artoni A, Greppi N, Vecchio S, Fagiolari G, Moggio M, Comi GP, Mistraletti G, Lanticina B, Faraldi L, Gattinoni L: Metformin overdose causes platelet mitochondrial dysfunction in humans. Crit Care 2012, 16: R180. 10.1186/cc11663
Wagner K, Wachter U, Vogt JA, Scheuerle A, McCook O, Weber S, Gröger M, Stahl B, Georgieff M, Möller P, Bergmann A, Hein F, Calzia E, Radermacher P, Wagner F: Adrenomedullin binding improves catecholamine responsiveness and kidney function in resuscitated murine septic shock. Intensive Care Med Exp 2013, 1: 2. 10.1186/2197-425X-1-2
Hardie DG: Sensing of energy and nutrients by AMP-activated protein kinase. Am J Clin Nutr 2011, 93: 891S-896S. 10.3945/ajcn.110.001925
Wagner F, Wagner K, Weber S, Stahl B, Knöferl MW, Huber-Lang M, Seitz DH, Asfar P, Calzia E, Senftleben U, Gebhard F, Georgieff M, Radermacher P, Hysa V: Inflammatory effects of hypothermia and inhaled H2 S during resuscitated, hyperdynamic murine septic shock. Shock 2011, 35: 396–402. 10.1097/SHK.0b013e3181ffff0e
Wagner F, Scheuerle A, Weber S, Stahl B, McCook O, Knöferl MW, Huber-Lang M, Seitz DH, Thomas J, Asfar P, Szabó C, Möller P, Gebhard F, Georgieff M, Calzia E, Radermacher P, Wagner K: Cardiopulmonary, histologic, and inflammatory effects of intravenous Na2 S after blunt chest trauma-induced lung contusion in mice. J Trauma 2011, 71: 1659–1667. 10.1097/TA.0b013e318228842e
Baumgart K, Wagner F, Gröger M, Weber S, Barth E, Vogt JA, Wachter U, Huber-Lang M, Knöferl MW, Albuszies G, Georgieff M, Asfar P, Szabó C, Calzia E, Radermacher P, Simkova S: Cardiac and metabolic effects of hypothermia and inhaled hydrogen sulfide in anesthetized and ventilated mice. Crit Care Med 2010, 38: 588–595. 10.1097/CCM.0b013e3181b9ed2e
Reinelt H, Radermacher P, Fischer G, Geisser W, Wachter U, Wiedeck H, Georgieff M, Vogt J: Effects of a dobutamine-induced increase in splanchnic blood flow on hepatic metabolic activity in patients with septic shock. Anesthesiology 1997, 86: 818–824. 10.1097/00000542-199704000-00012
Dahn MS, Mitchell RA, Lange MP, Smith S, Jacobs LA: Hepatic metabolic response to injury and sepsis. Surgery 1995, 117: 520–530. 10.1016/S0039-6060(05)80251-X
Groeger M, Matallo J, McCook O, Wagner F, Wachter U, Bastian O, Gierer S, Reich V, Stahl B, Huber-Lang M, Szabó C, Georgieff M, Radermacher P, Calzia E, Wagner K: Temperature and cell-type dependency of sulfide effects on mitochondrial respiration. Shock 2012, 38: 367–374. 10.1097/SHK.0b013e3182651fe6
Viollet B, Guigas B, Sanz Garcia N, Leclerc J, Foretz M, Andreelli F: Cellular and molecular mechanisms of metformin: an overview. Clin Sci (Lond) 2012, 122: 253–270. 10.1042/CS20110386
Team SD: Stan: a C++ library for probability and sampling, version 2.0. 2014. Available from http://mc-stan.org/
Lunn D, Spiegelhalter D, Thomas A, Best N: The BUGS project: evolution, critique and future directions. Stat Med 2009, 28: 3049–3067. 10.1002/sim.3680
Regueira T, Bänziger B, Djafarzadeh S, Brandt S, Gorrasi J, Takala J, Lepper PM, Jakob SM: Norepinephrine to increase blood pressure in endotoxaemic pigs is associated with improved hepatic mitochondrial respiration. Crit Care 2008, 12: R88. 10.1186/cc6956
Francés DE, Ronco MT, Monti JA, Ingaramo PI, Pisani GB, Parody JP, Pellegrino JM, Sanz PM, Carrillo MC, Carnovale CE: Hyperglycemia induces apoptosis in rat liver through the increase of hydroxyl radical: new insights into the insulin effect. J Endocrinol 2010, 205: 187–200. 10.1677/JOE-09-0462
Saandeep K, Vikram A, Tripathi DN, Ramarao P, Jena G: Influence of hyperglycemia on chemical-induced toxicity: study with cyclophosphamide in rat. Basic Clin Pharmacol Toxicol 2009, 105: 236–242. 10.1111/j.1742-7843.2009.00433.x
Chandrasekaran K, Swaminathan K, Chatterjee S, Dey A: Apoptosis in HepG2 cells exposed to high glucose. Toxicol Vitro 2010, 24: 387–396. 10.1016/j.tiv.2009.10.020
Kushwaha S, Vikram A, Jena GB: Protective effects of enalapril in streptozotocin-induced diabetic rat: studies of DNA damage, apoptosis and expression of CCN2 in the heart, kidney and liver. J Appl Toxicol 2012, 32: 662–672. 10.1002/jat.1670
Lablanche S, Cottet-Rousselle C, Lamarche F, Benhamou PY, Halimi S, Leverve X, Fontaine E: Protection of pancreatic INS-1 β-cells from glucose- and fructose-induced cell death by inhibiting mitochondrial permeability transition with cyclosporin A or metformin. Cell Death Dis 2011, 2: e134. 10.1038/cddis.2011.15
Yuan H, Li L, Zheng W, Wan J, Ge P, Li H, Zhang L: Antidiabetic drug metformin alleviates endotoxin-induced fulminant liver injury in mice. Int Immunopharmacol 2012, 12: 682–688. 10.1016/j.intimp.2012.01.015
Li B, Chauvin C, De Paulis D, De Oliveira F, Gharib A, Vial G, Lablanche S, Leverve X, Bernardi P, Ovize M, Fontaine E: Inhibition of complex I regulates the mitochondrial permeability transition through a phosphate-sensitive inhibitory site masked by cyclophilin D. Biochim Biophys Acta 2012, 1817: 1628–1634. 10.1016/j.bbabio.2012.05.011
Simkova V, Baumgart K, Vogt JA, Wachter U, Weber S, Gröger M, Speit S, Radermacher P, Albuszies G, Barth E: The effect of SOD-1 over-expression on hepatic gluconeogenesis and whole-body glucose oxidation during resuscitated, normotensive murine septic shock. Shock 2008, 30: 578–584. 10.1097/SHK.0b013e31816a6e0f
Raza H, Prabu SK, John A, Avadhani NG: Impaired mitochondrial respiratory functions and oxidative stress in streptozotocin-induced diabetic rats. Int J Mol Sci 2011, 12: 3133–3147. 10.3390/ijms12053133
Nikam A, Patankar JV, Lackner C, Schöck E, Kratky D, Zatloukal K, Abuja PM: Transition between acute and chronic hepatoxicity in mice is associated with impaired energy metabolism and induction of mitochondrial heme oxygenase-1. PLoS One 2013, 8: e66094. 10.1371/journal.pone.0066094
Piantadosi CA, Withers CM, Bartz RR, MacGarvey NC, Fu P, Sweeney TE, Welty-Wolf KE, Suliman HB: Heme oxygenase-1 couples activation of mitochondrial biogenesis to anti-inflammatory cytokine expression. J Biol Chem 2011, 286: 16374–16385. 10.1074/jbc.M110.207738
MacGarvey NC, Suliman HB, Bartz RR, Fu P, Withers CM, Welty-Wolf KE, Piantadosi CA: Activation of mitochondrial biogenesis by heme oxygenase-1-mediated NF-E2-related factor-2 induction rescues mice from lethal Staphylococcus aureus sepsis. Am J Respir Crit Care Med 2012, 185: 851–861. 10.1164/rccm.201106-1152OC
Ndisang JF, Jadhav A: Heme oxygenase system enhances insulin sensitivity and glucose metabolism in streptozotocin-induced diabetes. Am J Physiol Endocrinol Metab 2009, 296: E829-E841. 10.1152/ajpendo.90783.2008
Ndisang JF, Jadhav A: Up-regulating the hemeoxygenase system enhances insulin sensitivity and improves glucose metabolism in insulin-resistant diabetes in Goto-Kakizaki rats. Endocrinology 2009, 150: 2627–2636. 10.1210/en.2008-1370
Iwasaki K, Miwa Y, Haneda M, Kuzuya T, Ogawa H, Onishi A, Kobayashi T: AMP-activated protein kinase as a promoting factor, but complement and thrombin as limiting factors for acquisition of cytoprotection: implications for induction of accommodation. Transpl Int 2013, 26: 1138–1148. 10.1111/tri.12186
Kim SA, Choi HC: Metformin inhibits inflammatory response via AMPK-PTEN pathway in vascular smooth muscle cells. Biochem Biophys Res Commun 2012, 425: 866–872. 10.1016/j.bbrc.2012.07.165
Liu XM, Peyton KJ, Shebib AR, Wang H, Korthuis RJ, Durante W: Activation of AMPK stimulates heme oxygenase-1 gene expression and human endothelial cell survival. Am J Physiol Heart Circ Physiol 2011, 300: H84-H93. 10.1152/ajpheart.00749.2010
Tsoyi K, Jang HJ, Nizamutdinova IT, Kim YM, Lee YS, Kim HJ, Seo HG, Lee JH, Chang KC: Metformin inhibits HMGB1 release in LPS-treated RAW 264.7 cells and increases survival rate of endotoxaemic mice. Br J Pharmacol 2011, 162: 1498–1508. 10.1111/j.1476-5381.2010.01126.x
Brownlee M: The pathobiology of diabetic complications: a unifying mechanism. Diabetes 2005, 54: 1615–1625. 10.2337/diabetes.54.6.1615
Albuszies G, Radermacher P, Vogt J, Wachter U, Weber S, Schoaff M, Georgieff M, Barth E: Effect of increased cardiac output on hepatic and intestinal microcirculatory blood flow, oxygenation, and metabolism in hyperdynamic murine septic shock. Crit Care Med 2005, 33: 2332–2338. 10.1097/01.CCM.0000182817.20977.E9
This article is dedicated to the late Prof. Xavier M. Leverve who intiated this study, supported by an unrestricted grant of Poxel SAS, Lyon, France. Very special thanks are dedicated to Rosemarie Mayer, Rosa Maria Engelhardt, Tanja Schulz, and Ingrid Eble for their skillful technical assistance.
The authors declare that they have no competing interests.
PR, PA, MGe, EF, and XL designed the experiment. UW was responsible for the mass spectrometer measurements to assess glucose labeling and oxidation. SW MGr and KW performed the anesthesia, surgery, and subsequent intensive care management. BS and FW were responsible for all immuno-biology measurements. EC was responsible for the mitochondrial analysis. JAV performed the mathematical modeling. JAV, PR, PA, MGe, and EF wrote the paper. All authors read and approved the final manuscript.
